Carriage for Forklift - There are actually 4 sizes of hook type blade carriages rated by the blade carriage lifting capacity. Hook type tine carriages have been uniform.
The carriage bar spacing utilized for Class 1 is approximately 13 inches and the Class 1 carriage is rated to carry loads as much as 2000lbs. The Class 2 carriage is rated to carry cargo up to 5,500lbs with carriage bar spacing of sixteen inches. Class III carriages are rated for loads up to 10,000 lbs. The carriage bar spacing for this class is 20 inches. Class IV carriages are rated for cargo as much as 15,500 lbs. The carriage bar spacing used for this capacity is 25 inches.
The carriages for pin type tines may be different depending on the manufacturer. Pin mounted blades may differ by the amount of offset between the tine eye and the tine. Carriage capacity will be determined by the carriage pin size and by the fork size.
